Detail produk:

Harga terbaik Kontak

Informasi Detail
Menyoroti:

Gearbox Ayunan Excavator

,

Perlengkapan Pengurang Ayunan

,

Swing Drive Gearbox

Deskripsi Produk

Parameter produk
Pnama seni
 SK460 SK485 Swing gearbox
Peralatan Mendaftar ke Kobelco EXKAVATOR
Bagian no. LS32W00012F1
NO.1 gigi spline gear matahari 13 spline
Gigi poros swing pinion 11T
Kondisi barang Baru
Logo LB
Berat kotor

...
MOQ 1 pcs


Deskripsi produk

SK460-8 SK485 PEREDAM SWING LS32W00012F1 SK460-8 SWING GEARBOX 0SK460-8 SK485 PEREDAM SWING LS32W00012F1 SK460-8 SWING GEARBOX 1SK460-8 SK485 PEREDAM SWING LS32W00012F1 SK460-8 SWING GEARBOX 2SK460-8 SK485 PEREDAM SWING LS32W00012F1 SK460-8 SWING GEARBOX 3SK460-8 SK485 PEREDAM SWING LS32W00012F1 SK460-8 SWING GEARBOX 4

Bagian pada kelompok (SK485-8) - ACERA MARK 8 EXCAVATOR - TIER 3 (NA) YS07U0701 - (8/07-12/12):

Posisi. Bagian No. Qty Nama bagian Komentar
. . LS32W00012F1 [1] Peralatan hidraulik KOB Swing Reduction Assembly (persatuan pengurangan ayunan)
1. LQ32W01038P1 [1] Jari pantat. KOB
2. LQ32W01027P1 [1] SHAFT, PLANETAR CAR KOB
3. LQ32W01011P1 [4] Pengemudi SPROCKET KOB
4. LQ32W01031F1 [1] Spider KOB
5. LQ32W01010P1 [1] Gear KOB
6. LQ32W01009P1 [4] Pengemudi SPROCKET KOB
7. LQ32W01005P1 [1] RING GEAR KOB
8. 2413J376 [1] DIFF. Spider KOB
9. 2410T352 [4] ROLLER SHAFT KOB
10. 2425Z540 [4] PEMANGAT jarum, 40mm ID x 48mm OD x 25mm W KOB
11. 2425Z541 [4] PEMANGAT jarum, 40mm ID x 54mm OD x 50mm W KOB
12. LQ32W01016P1 [1] Bantalan Bola KOB
13. LQ32W01015P1 [1] Bantalan Bola KOB
14. LQ32W01035P1 [1] OIL SEAL KOB
15. NA [1] Tidak dilayani Untuk Perumahan
16. LC32W01033P1 [1] OIL SEAL KOB
17. LQ32W01036P1 [1] Sleeve KOB
18. LQ32W01037P1 [8] PEMANAS KOB
19. LQ32W01018P1 [8] PEMANAS KOB Dorongan
20. ZR16X04000 [4] RING KOB Pengaman -- ID 37 x OD 40 x Th 1,8 mm
21. ZR16X10000 [1] RING KOB Retaining -- ID 94.50 x OD 119 x Th 3.0mm
22. ZP26D08032 [4] PIN KOB Roll -- OD 08 x 32mm Panjang
23. ZS23C14150 [16] Sekrup, Kepala Soket Hex, M14 x 150mm KOB M14x2.0x150mm
24. PV02B01073DB [2] PDB KOB 18,4mm Plastik
