• 404-00094B 130426-00014 2401-9279A Swing Gearbox DH370 SOLAR330 SOLAR340 Swing Reduction Gear
  • 404-00094B 130426-00014 2401-9279A Swing Gearbox DH370 SOLAR330 SOLAR340 Swing Reduction Gear
  • 404-00094B 130426-00014 2401-9279A Swing Gearbox DH370 SOLAR330 SOLAR340 Swing Reduction Gear
  • 404-00094B 130426-00014 2401-9279A Swing Gearbox DH370 SOLAR330 SOLAR340 Swing Reduction Gear
404-00094B 130426-00014 2401-9279A Swing Gearbox DH370 SOLAR330 SOLAR340 Swing Reduction Gear

404-00094B 130426-00014 2401-9279A Swing Gearbox DH370 SOLAR330 SOLAR340 Swing Reduction Gear

Detail produk:

Harga terbaik Kontak

Informasi Detail
Menyoroti:

130426-00014 Swing Gearbox

,

2401-9279A Swing Gearbox

,

Perlengkapan pengurangan ayunan SOLAR340

Deskripsi Produk

DH370 SOLAR330 SOLAR340 Swing REDUCTION GEAR 404-00094 404-00094A 404-00094B 130426-00014 2401-9279A Swing Gearbox

Parameter produk
Pnama seni DH370 SOLAR330 SOLAR340 Swing gearbox
Peralatan Berlaku untuk DOOSAN EXKAVATOR
Bagian no. 404-00094 130426-00014 2401-9279A
NO.1 gigi spline gear matahari 20 spline
Gigi poros swing pinion 14T
Kondisi barang Baru
Logo LB
Berat kotor 335 KG
MOQ 1 pcs

Deskripsi produk

404-00094B 130426-00014 2401-9279A Swing Gearbox DH370 SOLAR330 SOLAR340 Swing Reduction Gear 0404-00094B 130426-00014 2401-9279A Swing Gearbox DH370 SOLAR330 SOLAR340 Swing Reduction Gear 1

Bagian dari kelompok SOLAR 330LC-V:

404-00094B 130426-00014 2401-9279A Swing Gearbox DH370 SOLAR330 SOLAR340 Swing Reduction Gear 2

Posisi. Bagian No. Qty Nama bagian Komentar
-. 404-00094 [1] Gear;REDUKSI
1. 105-00011 [1] SHAFT
10. 104-00038 [1] Gear;SUN NO.1
11. 104-00042 [3] Gear;Planetary NO.1
12. 223-00044 [3] Plat; NO. sisi.1
13. 123-00457 [3] PIN ASSY
14. 104-00040 [1] Gear;RING
15. 223-00045 [1] PLATE;THRUST
16. 621-02348 [1] PELUAR
17. 705-00008 [4] PIN; LOCK
18. 114-00543 [1] SPACER
19. 114-00544 [1] KOLER
2. 423-00172 [1] CASE;GEAR
20. 159-00233 [1] PELAT
21. 278-00090 [1] RING;LOCK
22. 109-00168 [1] Bantalan; Roller Sferik
23. 109-00169 [1] Bantalan; Roller Sferik
24. 180-00444 [1] SEAL; Minyak
25. S5741361 [4] PIN;SPRING
26. S5810030 [1] PLUG
27. S5810010 [2] PLUG
28. S5810050 [1] PLUG
29. 120-00294 [16] BOLT;SOCKET M16X180
3. 230-00056 [1] Pengangkut No.2
30. 140-01343 [1] PIPE
31. 119-00020 [1] BAR;LEVEL
32. 120-00293 [4] BOLT;SOCKET M16X40
33. 223-00046 [3] Plat; NO. sisi.3
34. S6500400 [3] Cincin, mempertahankan
35. 230-00064 [1] Pengangkut No.1 ASSY
36. 230-00065 [1] Pengangkut No.2 ASSY
4. 104-00039 [1] Gear;SUN NO.2
5. 104-00037 [4] Gear;Planetary NO.2
6. 223-00043 [4] Plat; NO. sisi.2
7. 123-00459 [4] SHAFT untuk PIN NO.2
8. 110-00228 [4] Bush tidak.2
9. 230-00057 [1] Pengangkut No.1
