Detail produk:

Harga terbaik Kontak

Informasi Detail
Menyoroti:

31NA-10150 Swing drive gearbox

,

31NA-10151 Swing drive gearbox

,

R380-9 Pengurangi ayunan

Deskripsi Produk

R375-7 R385-9 R380-9 R360-7 Swing Reducer 31NA-10150 31NA-10151 31NA-10152 31QA-10140 31QA-10141 R360 Swing Gearbox

Parameter produk
Pnama seni R375-7 R385-9 R380-9 R360-7 Swing gearbox
Peralatan Memohon untuk HYUNDAI EXKAVATOR
Bagian no. 31NA-10150 31QA-10140
NO.1 gigi spline gear matahari 20 spline
Gigi poros swing pinion 15T
Kondisi barang Baru
Logo LB
Berat kotor 345 KG
MOQ 1 pcs

Deskripsi Produk

31NA-10150 31NA-10151 31NA-10152 Swing Drive Gearbox R375-7 R385-9 R380-9 Swing Reducer 031NA-10150 31NA-10151 31NA-10152 Swing Drive Gearbox R375-7 R385-9 R380-9 Swing Reducer 1

Bagian-bagian pada kelompok Swing REDUCTION GEAR ((#0063-):

31NA-10150 31NA-10151 31NA-10152 Swing Drive Gearbox R375-7 R385-9 R380-9 Swing Reducer 2

Posisi. Bagian No. Qty Nama bagian Komentar
*-2. 31NA-10150 [1] Gear pengurangan ayunan
1. XKAQ-00144 [1] KASING
2. XKAQ-00145 [1] SHAFT-DRIVE
2. XKAQ-00300 [1] SHAFT-DRIVE Lihat ILLUST
3. XKAQ-00146 [1] Berkas-Roller
4. XKAQ-00147 [1] Plat-COVER
5. XKAQ-00148 [8] BOLT-HEX
6. XKAQ-00149 [1] SEAL-OIL
7. XKAQ-00027 [1] Berkas-Roller
* XKAQ-00263 [1] Pengangkut ASSY-NO 2
* XKAQ-00264 [1] Pengangkut ASSY-NO 2 Lihat ILLUST
8. XKAQ-00150 [1] Pengangkut 2
8. XKAQ-00251 [1] Pengangkut 2 Lihat ILLUST
10. XKAQ-00152 [4] GEAR-PLANET 2
10. XKAQ-00253 [4] GEAR-PLANET 2 Lihat ILLUST
11. XKAQ-00153 [4] PIN ASSY 2
11. XKAQ-00254 [4] PIN 2 Lihat ILLUST
N12. @ [4] BUSHING
N12. @ [4] BUSHING Lihat ILLUST
N33. @ [4] Pin-SPRING
13. XKAQ-00050 [4] Pin-SPRING
14. XKAQ-00156 [4] Kekuatan pencuci
* XKAQ-00261 [1] Pengangkut ASSY-NO 1
* XKAQ-00262 [1] Pengangkut ASSY-NO 1 Lihat ILLUST
15. XKAQ-00157 [1] Pengangkut 1
15. XKAQ-00325 [1] Pengangkut 1
16. XKAQ-00158 [1] Gear-SUN 1
16. XKAQ-00257 [1] Gear-SUN 1 Lihat ILLUST
17. XKAQ-00774 [4] GEAR-PLANET 1
18. XKAQ-00019 [4] PIN 1
19. XKAQ-00030 [4] Jarum kandang
20. XKAQ-00040 [4] Sisi Plat 2
21. XKAQ-00048 [4] Pin-SPRING
22. XKAQ-00160 [1] GANG-RING
22. XKAQ-00258 [1] GANG-RING Lihat ILLUST
23. XKAQ-00072 [4] PIN-KNOCK
24. XKAQ-00161 [16] BOLT-SOCKET
24. XKAQ-00259 [16] BOLT-SOCKET Lihat ILLUST
25. XKAQ-00162 [1] SPACER
26. XKAQ-00163 [1] Gear-pinion
27. XKAQ-00164 [1] PLATE-LOCK
27. XKAQ-00299 [1] PLATE-LOCK Lihat ILLUST
28. XKAQ-00042 [2] BOLT-HEX
28. XKAQ-00042 [4] BOLT-HEX Lihat ILLUST
29. XKAQ-00041 [1] RING-STOP
30. XKAQ-00273 [1] PLUG
31. XKAQ-00274 [2] PLUG
32. XKAQ-00057 [4] Sisi Plat 1
34. XKAQ-00166 [1] BAR-GAUGE
35. XKAQ-00167 [1] PIPE-GAUGE
36. XKAQ-00168 [1] LAMPUNG LAUNCHER
36. XKAQ-00292 [2] LAMPUNG LAUNCHER Lihat ILLUST
37. XKAQ-00169 [1] PELUAR
38. XKAQ-00170 [4] BOLT-SOCKET
39. XKAQ-00155 [1] Plug-Socket
40. XKAQ-00171 [1] RING-SPACEER
41. XKAQ-00076 [1] Plate-thrust
41. XKAQ-00260 [1] Kekuatan RING-THRUST Lihat ILLUST
42. XKAQ-00143 [1] Respirator pasca-udara
43. XKAQ-00151 [1] Gear-SUN 2
43. XKAQ-00252 [1] Gear-SUN 2 Lihat ILLUST
N. @ [1] Bagian-bagian yang tidak disuplai
